HIOKI Digital Insulation Tester IR4052 - 50 (Replacement for IR4052 - 10)
Product Overview
Product Specifications
| Country of Origin | Japan |
|---|---|
| Minimum Order Quantity / Order Unit | 1PC/ 1PC |
| Type | Compliant Standard JIS C 1302: 2018 |
| Size | 152x92x40mm/ 440g |
| Rated Measurement Voltage | DC 50/ 125/ 250/ 500/ 1000V |
| Effective Maximum Display Value | 100/ 250/ 500/ 2000/ 4000MΩ |
| Accuracy First Effective Measurement Range MΩ | 0.200~10.00/ 0.200~25.0/ 0.200~50.0/ 0.200~500/ 0.200~1000 (All ±4% rdg.) |
| Lower Limit Resistance Capable of Maintaining Rated Measurement Voltage | 0.05/ 0.125/ 0.25/ 0.5/ 1MΩ |
| Overload Protection | AC 600/ 600/ 600/ 600/ 660V (All 10s) |
| DC Voltage Range | 4.2V (0.001V resolution) to 600V (1V resolution), 4 ranges, Accuracy: ±1.3%rdg. ±4dgt, Input Resistance: 100kΩ or more |
| AC Voltage Range | 420V (0.1V resolution)/ 600V (1V resolution), 2 ranges, 50/ 60Hz, Accuracy: ±2.3%rdg. ±8dgt, Input Resistance: 100kΩ or more, True RMS |
| Low Resistance Range | For earth wire continuity check, 10Ω (0.01Ω resolution) to 1000Ω (1Ω resolution), 3 ranges, Basic Accuracy: ±3%rdg. ±2dgt., Measurement Current: 200mA or more (at 6Ω or less) |
| Display | Transflective FSTN LCD, Backlight, Bar Graph |
| Response Time | Comparator judgment response time: Approx. 0.3 seconds (under HIOKI specified conditions) |
| Functions | Insulation resistance digit switching, 1 - minute value display, Live line warning, Automatic discharge, AC/ DC auto detection, Comparator, Drop - proof, Auto power save |
| Compliant Standards | JIS C 1302:2018 |
| Power Source | AA alkaline batteries (LR6) x 4, Continuous use time: 20h (under HIOKI specified conditions) |
| Dimensions and Mass | 152x92x40mm/ 440g (including batteries, excluding test leads) |
| Included Accessories for IR4052-50 | Test Lead L9787 x 1, Carrying Case C0108 x 1, Instruction Manual x 1, AA Alkaline Batteries (LR6) x 4 |
| Model Name | IR4052 - 50 |
| Brand | HIOKI |
| Origin | Japan |
| Manufacturer | HIOKI |
| Minimum Order | 1PC/ 1PC |
Product Details
| Brand / Manufacturer | HIOKI |
|---|---|
| Model | IR4052 - 50 |
| Category | Insulation Testers |
| Unit | EA |
| Condition | New |
| Availability | Quote Available |
| Warranty | 12 Months Warranty |
